PolyForce24i Tracked

Arguably the fastest, safest, most consistent butt welding machine manufactured in Australia. Thanks to 5 years of research and development, coupled with Worldpolys' 60 years of PE pipeline experience the PolyForce24i ensures consistent butt welding.



Worldpoly machines operate with far less downtime than you've become used to.

Technical Specifications


Capacity 250 to 630mm. Includes two-piece clamp inserts for pipe and fittings diameters 630, 500, 450, 400, 355, 315, 280 and 250mm are included unless otherwise confirmed
Track mounted. Self contained and self propelled with cordless remote and data logging
CNC welding according to ISO 21307 Single High Pressure
Hydraulic in/out facing tool and heating plate with crash protection. No longer are these considered consumables
Hydraulic open/close/locking of main clamps without operator contact. Impossible to crash main clamps with facing tool and heating plate.
Simple operation. Automatic or manual butt fusion. 20,000+ weld data logging included. 3.5 second changeover time for 630mm (24") SDR 11 in Automatic mode
Locally serviceable.
Pipe clamps prevent slippage even under extreme conditions, which is detected by the machine in case of undersized pipe
External hydraulic pipe lifters front and rear for operator safety
Industry Standard track assembly, Bridgestone specification rubber tracks, two-speed, automatic braking when stopped
Butt welding unit easily removed for site and trench work
Australian made, built tough, locally serviceable, low-noise. Just what you've been looking for
Welded steel machine frame and two-speed rubber tracked base
Rated lifting points on welding machine and frame, optional spreader bar
Engine - Yanmar 2216 cc, 4 cylinder, 70 litres, 1800 RPM low-noise diesel lasts 12 hours under normal conditions. Tier 4 for North America.
Weight - 3800 kg


Maximum pump operating pressure - 200 bar / 20 MPa
Total cylinder section - 3660mm², 7200mm² or 13,000mm²


Genuine 3 year International warranty
