PolyWorkshop48i LF
Hydraulically operated CNC controlled workshop machine for the butt-welding of pipes and fittings in PE, PP and other thermoplastic materials. Pivoting clamps allow for the fabrication of fittings having different radii. Included are hydraulic open
Hydraulically operated CNC controlled workshop machine for the butt-welding of pipes and fittings in PE, PP and other thermoplastic materials. Pivoting clamps allow for the fabrication of fittings having different radii. Included are hydraulic open/close/locking main clamps and insert liners required to produce 20" to 48" segment welded bends, manual open/close/locking mains clamps and insert liners required to produce 24" to 48" segment welded 90 degree tees and crosses. Optional main clamps are available to produce branch tees and true-wyes 24" to 48". Welding operations are at both high (ASTM F 2620-13) and low (ISO, DVS, POP 003) interface force. CNC touch-screen control of welding operations and integral 20,000+ weld data logger are standard.
Read More REQUEST A QUOTESAFETY
PolyWorkshop48i workshop welding machine including hydraulic open/close/locking main bend clamps, manual open/close/locking main tee and cross clamps, and all reducing liners required to produce bends, tees and crosses diameter 24" to 48" IPS. Touch screen CNC operation with internal data logger.
Technical Specifications
General
Welding range 20" to 32" DR 5 to DR 32, 36" DR 7.4 to 32, 42" DR 9 to 32, 48" DR 11 to 32 |
CNC touch-screen control of welding operations and integral data logger are standard. |
Welding operations are at both high (ASTM) interface force and low (ISO, POP 003, DVS) low force |
Specifications subject to change without notice. Please check at time of order confirmation. |
