Worldpoly2500 Hydra LF

Worldpoly2500 Hydra LF hydraulically operated butt-welding machine suitable for PE and PP pipes and fittings to 2500mm OD. Includes hydraulic open/close/locking clamps to weld pipes 2500mm, 2250mm and 2000mm with optional reducing liners 1800mm and

Read More REQUEST A QUOTE

SAFETY

Worldpoly2500 Hydra HF butt welding machine including hydraulic main frame with clamps 2500mm, hydraulic open/close and locking of main clamps, tablet controlled CNC operation with 20,000+ weld data logging, and electric facing tool & heating plate with stand.

Standard Features

  • Welding range to 2500mm, alternatively 100" IPS, SDR 17
  • Hydraulic open / close / locking of main clamps
  • Genuine 2 year international warranty, backed by Australian and International Law
  • Tablet operated with CNC control of temperature, time and pressure functions. Operator can move around the machine during welding.
  • Research, design and development by Worldpoly Australia
  • Commissioning, training and warranty by Worldpoly Australia
  • Includes 20,000+ weld data logger.
  • Removable cast Aluminium electric facing tool with current overload protection.
  • Removable cast Aluminium PTFE coated heating plate with electronic temperature control.
  • Stand for heating plate and facing tool. Optional trolley base.
  • On-board electrohydraulic pump with controls, accumulator and quick release hoses. Includes countdown timers for heating and cooling phases.
  • Optional trolley base.
  • 480 volt 60 Hz 3 phase. 128 kW / 205 A
  • Total cylinder section 142.54cm2 / 14254mm²
  • Maximum clamping pressure 16 Mpa
  • Please note technical specifications of Worldpoly machines may change without notice. Please confirm at time of order.

Technical Specifications

General

Welding range to 2500mm, alternatively 100" IPS, SDR 17
Hydraulic open / close / locking of main clamps
Tablet operated with CNC control of temperature, time and pressure functions. Operator can move around the machine during welding.
Research, design and development by Worldpoly Australia
Commissioning, training and warranty by Worldpoly Australia
Includes 20,000+ weld data logger.
Removable cast Aluminium electric facing tool with current overload protection.
Removable cast Aluminium PTFE coated heating plate with electronic temperature control.
Stand for heating plate and facing tool. Optional trolley base.
On-board electrohydraulic pump with controls, accumulator and quick release hoses. Includes countdown timers for heating and cooling phases.
Maximum clamping pressure 16 Mpa
Please note technical specifications of Worldpoly machines may change without notice. Please confirm at time of order.

Warranty

Genuine 2 year international warranty, backed by Australian and International Law

Options

Optional trolley base.

Electric

480 volt 60 Hz 3 phase. 128 kW / 205 A

Hydraulic

Total cylinder section 142.54cm2 / 14254mm²
