Worldpoly250 HF

High-pressure welding. Worldpoly 250 High Pressure is a hydraulically operated butt-welding machine suitable for PE and fittings from 63 to 250mm OD using high pressure welding methods. Excellent Australian Engineered design and construction provi

Read More REQUEST A QUOTE

SAFETY

Worldpoly250 High Pressure welding machine. Includes hydraulic main frame with electric facing tool & heating plate, stand and hydraulic control unit.

Standard Features

  • Welding range 50 to 250mm SDR 9 (PN20) to SDR 17. 63 to 125mm SDR 9 and 11 only.
  • Complete and ready to weld - Genuine 2 year warranty on parts
  • Included as standard (unless otherwise specified):
  • - Main frame, including 4 light weight pressure-cast alloy main clamps of 250mm diameter
  • - Removable cast Aluminium electric facing tool with current overload protection
  • - Electrohydraulic pump with controls, and quick release hoses. Includes countdown timers for heating and cooling phases
  • - PTFE coated heating plate with electronic temperature control (heating plate automatically separates from pipe ends after heating)
  • - Stand for heating plate and facing tool
  • - Tool box including tools, bolts, selected spare parts, etc
  • - German hydraulic seals
  • - Wired ready to accept Worldpoly or other data logger
  • Clamp options include (machine can be supplied with any combination of liner diameters):
  • - 2-piece liners: 250 x 225, 250 x 200, 250 x 180, 250 x 160, 250 x 140, 160 x 125, 160 x 110, 160 x 90, 160 x 75, 160 x 63 & 160 x 50mm
  • - Narrow clamps: 250x225, 250x200, 250x180, 250x160, 250x140, 250x125, 250x110, 250x90, 250x75, 250x63, 250x50mm
  • Optional stub end device for welding end fittings (available in aluminium or steel)
  • Optional wheeled trolley available
  • 230 volt 50/60 Hz 1 phase (5.4 kw 23.4A )
  • Requires generator minimum 230 volt 5 KVA - provide full machine details to generator supplier before purchase
  • Total cylinder section 11 cm2, maximum pump pressure 100 bar
  • Net weight 140 kg
  • Please note technical specifications of Worldpoly machines may change without notice
  • Australia only - This machine is supplied tested & tagged with 2 x 15 amp plugs

Technical Specifications

General

Welding range 50 to 250mm SDR 9 (PN20) to SDR 17. 63 to 125mm SDR 9 and 11 only.
Complete and ready to weld - Genuine 2 year warranty on parts
Included as standard (unless otherwise specified):
- Main frame, including 4 light weight pressure-cast alloy main clamps of 250mm diameter
- Removable cast Aluminium electric facing tool with current overload protection
- Electrohydraulic pump with controls, and quick release hoses. Includes countdown timers for heating and cooling phases
- PTFE coated heating plate with electronic temperature control (heating plate automatically separates from pipe ends after heating)
- Stand for heating plate and facing tool
- Tool box including tools, bolts, selected spare parts, etc
- Wired ready to accept Worldpoly or other data logger
Net weight 140 kg
Please note technical specifications of Worldpoly machines may change without notice

Hydraulic

- German hydraulic seals
Total cylinder section 11 cm2, maximum pump pressure 100 bar

Options

Clamp options include (machine can be supplied with any combination of liner diameters):
- 2-piece liners: 250 x 225, 250 x 200, 250 x 180, 250 x 160, 250 x 140, 160 x 125, 160 x 110, 160 x 90, 160 x 75, 160 x 63 & 160 x 50mm
- Narrow clamps: 250x225, 250x200, 250x180, 250x160, 250x140, 250x125, 250x110, 250x90, 250x75, 250x63, 250x50mm
Optional stub end device for welding end fittings (available in aluminium or steel)
Optional wheeled trolley available

Electric

230 volt 50/60 Hz 1 phase (5.4 kw 23.4A )
Requires generator minimum 230 volt 5 KVA - provide full machine details to generator supplier before purchase
Australia only - This machine is supplied tested & tagged with 2 x 15 amp plugs
