Worldpoly1200 LF

Worldpoly1200/48 hydraulically operated butt-welding machine, suitable for PE and PP pipes and fittings from 630 to 1200mm OD, alternatively 24 to 48". Available to weld according to ISO/DVS/POP003 SLP & DLP low pressure. The machine is the re

Read More REQUEST A QUOTE

SAFETY

Worldpoly1200/48 butt welding machine including hydraulic main frame with clamps 1200mm / alt. 48", electric facing tool & heating plate with stand and hydraulic control unit.

Standard Features

  • Stand for heating plate and facing tool.
  • Electrohydraulic pump with controls, accumulator and quick release hoses. Includes countdown timers for heating and cooling phases.
  • Genuine 2 year international warranty.
  • Optional Aluminium or steel stub end device for welding end fittings.
  • Wired ready to accept Worldpoly or other data logger.
  • Tool box including tools, bolts etc.
  • Optional wheeled trolley available.
  • Optional 1,000kg crane assembly.
  • 400 volt 50/60 Hz 3 phase (29 kw, 47.3 A). 480 volt 3 phase 60 Hz also available
  • Minimum generator required: 400 volt 50 hz 3 phase, 32 KVA. Provide full machine details to generator supplier before purchase.
  • Weight 4,522kg (including crane and stub device)
  • Total cylinder area: 50.6cm2, maximum pump pressure 180 bar
  • Please note technical specifications of Worldpoly machines may change without notice
  • Welding range 630 to 1200mm: SDR 11 (PN16) to SDR 41 (PN4). 630 to 800mm: SDR 9 to SDR 41.
  • Welding force maximum 1200mm OD SDR 11, according to DVS 2207-1, ISO 21307 and POP003 low-pressure specifications.
  • Complete and ready to weld.
  • German hydraulic seals.
  • Main frame includes 4 light weight alloy main clamps of 1200mm diameter.
  • Layer clamps: 1200x1100, 1100x1000, 1000x900, 900x800, 800x710, 710x630.
  • Machine can be supplied with any combination of liner diameters.
  • Aluminium PTFE coated heating plate with electronic temperature control. Heating plate automatically releases from pipe ends after heating.
  • Electrically operated facing tool for correct preparation of pipe ends.

Technical Specifications

General

Stand for heating plate and facing tool.
Electrohydraulic pump with controls, accumulator and quick release hoses. Includes countdown timers for heating and cooling phases.
Tool box including tools, bolts etc.
Weight 4,522kg (including crane and stub device)
Please note technical specifications of Worldpoly machines may change without notice
Welding range 630 to 1200mm: SDR 11 (PN16) to SDR 41 (PN4). 630 to 800mm: SDR 9 to SDR 41.
Complete and ready to weld.
Main frame includes 4 light weight alloy main clamps of 1200mm diameter.
Aluminium PTFE coated heating plate with electronic temperature control. Heating plate automatically releases from pipe ends after heating.
Electrically operated facing tool for correct preparation of pipe ends.

Warranty

Genuine 2 year international warranty.

Options

Optional Aluminium or steel stub end device for welding end fittings.
Optional wheeled trolley available.
Optional 1,000kg crane assembly.
Layer clamps: 1200x1100, 1100x1000, 1000x900, 900x800, 800x710, 710x630.
Machine can be supplied with any combination of liner diameters.

Electric

Wired ready to accept Worldpoly or other data logger.
400 volt 50/60 Hz 3 phase (29 kw, 47.3 A). 480 volt 3 phase 60 Hz also available
Minimum generator required: 400 volt 50 hz 3 phase, 32 KVA. Provide full machine details to generator supplier before purchase.

Hydraulic

Total cylinder area: 50.6cm2, maximum pump pressure 180 bar
Welding force maximum 1200mm OD SDR 11, according to DVS 2207-1, ISO 21307 and POP003 low-pressure specifications.
German hydraulic seals.
