Worldpoly1000 Hydra HF

Worldpoly1000 HF hydraulically operated butt-welding machine, suitable for welding PE pipes and fittings from 500 to 1000mm OD ISO High Pressure Standards. The machine is the result of more than 60 consecutive years of direct involvement in the PE p

Read More REQUEST A QUOTE

SAFETY

Worldpoly1000 Hydra HF butt welding machine including hydraulic main frame with steel clamps 1000mm. Supplied with facing tool and heating plate in fitted stand.

Standard Features

  • Welding range 500mm to 1000mm: SDR 11 to SDR17. 500 to 630 SDR 9 / alt 20" to 36" SDR 11. 22" & 24" SDR 9.
  • Complete and ready to weld.
  • Main frame includes 4 laser cut steel main clamps of 1000mm.
  • Main clamps hydraulically open / close and lock.
  • German hydraulic seals.
  • Electrohydraulic pump with controls, accumulator and quick release hoses. Includes countdown timers for heating and cooling phases.
  • Optional stub end device for welding end fittings.
  • Wired ready to accept Worldpoly or other data logger.
  • Tool box including tools, bolts etc.
  • 400 volt 3 phase 50/60 Hz (33.4 kw, 50 A). Alt. 480 volt for North America.
  • Minimum generator required: 400 volt 43 KVA. Provide full machine details to generator supplier before purchase.
  • Weight 2,980kg (including stub device)
  • Total cylinder area: 43.60cm2, maximum pump pressure 180 bar
  • Genuine 2 year International warranty.
  • Please note technical specifications of Worldpoly machines may change without notice

Technical Specifications

General

Welding range 500mm to 1000mm: SDR 11 to SDR17. 500 to 630 SDR 9 / alt 20" to 36" SDR 11. 22" & 24" SDR 9.
Complete and ready to weld.
Main frame includes 4 laser cut steel main clamps of 1000mm.
Electrohydraulic pump with controls, accumulator and quick release hoses. Includes countdown timers for heating and cooling phases.
Wired ready to accept Worldpoly or other data logger.
Tool box including tools, bolts etc.
Weight 2,980kg (including stub device)
Genuine 2 year International warranty.

Warranty

Main clamps hydraulically open / close and lock.

Hydraulic

German hydraulic seals.
Total cylinder area: 43.60cm2, maximum pump pressure 180 bar

Options

Optional stub end device for welding end fittings.

Electric

400 volt 3 phase 50/60 Hz (33.4 kw, 50 A). Alt. 480 volt for North America.
Minimum generator required: 400 volt 43 KVA. Provide full machine details to generator supplier before purchase.

Please note technical specifications of Worldpoly machines may change without notice
