RELIABLE
Worldpoly machines operate with far less downtime than you've become used to.
Technical Specifications
General
| Welding range 50 to 250mm to SDR 9 (PN20) according to DVS 2207-1, ISO 21307 and POP003 low-pressure specifications. |
| Complete and ready to weld - Genuine 2 year warranty on parts |
| Included as standard (unless otherwise specified): |
| - Main frame, including 4 light weight pressure-cast alloy main clamps of 250mm diameter |
| - Removable cast Aluminium electric facing tool with current overload protection |
| - Electrohydraulic pump with controls, and quick release hoses. Includes countdown timers for heating and cooling phases |
| - PTFE coated heating plate with electronic temperature control (heating plate automatically separates from pipe ends after heating) |
| - Stand for heating plate and facing tool |
| - Tool box including tools, bolts, selected spare parts, etc |
| - Wired ready to accept Worldpoly or other data logger |
| Net weight 140 kg |
Hydraulic
| - German hydraulic seals |
| Total cylinder section 11 cm², maximum pump pressure 60 bar |
Electric
| 230 volt 50/60 Hz 1 phase (4.35 kw 15.6A ) |
| Requires generator minimum 230 volt 5 KVA - provide full machine details to generator supplier before purchase |
| Australia only - This machine is supplied tested & tagged with a 20amp plug |
Options
| Clamp options include (machine can be supplied with any combination of liner diameters): |
| - Layer clamps: 250x225, 225x200, 200x180, 180x160, 160x140, 140x125, 125x110, 110x90, 90x75, 75x63 & 63x50mm |
| - 2-piece liners: 250x225, 250x200, 250x180, 250x160, 160x140, 160x125, 160x110, 160x90, 160x75, 160x63, 160x50mm |
| - Narrow clamps: 250x225, 250x200, 250x180, 250x160, 250x140, 250x125, 250x110, 250x90, 250x75, 250x63 & 250x50mm |
| Optional stub end device for welding end fittings (available in aluminium or steel) |
| Optional wheeled trolley available |
Warranty
| Please note technical specifications of Worldpoly machines may change without notice |
